WDZ-RYY低煙無鹵護套線產品特性：
低煙無鹵電線電纜在火焰燃燒情況下產生極少量煙霧，釋放的氣體不含鹵元素，當火災發生時，可大大減少對儀器、設備和人體的危害的環保型電纜。
WDZ-RYY低煙無鹵護套線產品型號：
WDZ-RYY 低煙無鹵多芯電纜
WDZ-RYY低煙無鹵護套線電纜結構：
導體：無氧裸銅絲
絕緣：低煙無鹵環保型
護套：低煙無鹵環保型
顏色：黑色(RAL9005) 灰色(RAL7001)
工作電壓： 450/750V
測試電壓：＜0.5mm2：2000V ≥0.5mm2：2500V
使用溫度范圍：-20℃~+90℃
***小彎曲半徑：12x電纜外徑
WDZ-RYY低煙無鹵護套線電纜規格：
| 型號 | 規格 | 近似密度公斤/KM | 標稱外徑/下限mm | 外徑上限mm |
| WDZ-RYY | 0.5*2C | 34 | 5.4 | 5.8 |
| WDZ-RYY | 0.5*3C | 44 | 5.7 | 6.1 |
| WDZ-RYY | 0.5*4C | 55 | 6.2 | 6.6 |
| WDZ-RYY | 0.5*5C | 66 | 6.8 | 7.2 |
| WDZ-RYY | 0.5*6C | 76 | 7.4 | 7.8 |
| WDZ-RYY | 0.5*7C | 85 | 7.4 | 7.8 |
| WDZ-RYY | 0.5*8C | 104 | 8.4 | 8.8 |
| WDZ-RYY | 0.5*9C | 116 | 9.2 | 9.6 |
| WDZ-RYY | 0.5*10C | 128 | 9.8 | 10.2 |
| WDZ-RYY | 0.5*11C | 138 | 10.1 | 11.1 |
| WDZ-RYY | 0.5*12C | 146 | 10.1 | 11.1 |
| WDZ-RYY | 0.5*13C | 158 | 10.6 | 11.6 |
| WDZ-RYY | 0.5*14C | 166 | 10.6 | 11.6 |
| WDZ-RYY | 0.5*15C | 189 | 11.6 | 12.6 |
| WDZ-RYY | 0.5*16C | 197 | 11.6 | 12.6 |
| WDZ-RYY | 0.5*17C | 209 | 12.2 | 13.2 |
| WDZ-RYY | 0.5*18C | 218 | 12.2 | 13.2 |
| WDZ-RYY | 0.5*19C | 227 | 12.2 | 13.2 |
| WDZ-RYY | 0.5*20C | 237 | 12.5 | 13.5 |
| WDZ-RYY | 0.5*21C | 248 | 12.8 | 13.8 |
| WDZ-RYY | 0.5*22C | 261 | 13.6 | 14.6 |
| WDZ-RYY | 0.5*23C | 273 | 14.2 | 15.2 |
| WDZ-RYY | 0.5*24C | 295 | 14.6 | 15.6 |
| WDZ-RYY | 0.5*25C | 306 | 14.9 | 15.9 |
| WDZ-RYY | 0.5*26C | 315 | 14.9 | 15.9 |
| WDZ-RYY | 0.5*27C | 323 | 14.9 | 15.9 |
| WDZ-RYY | 0.5*28C | 335 | 15.4 | 17.4 |
| WDZ-RYY | 0.5*29C | 344 | 15.4 | 17.4 |
| WDZ-RYY | 0.5*30C | 353 | 15.4 | 17.4 |
| WDZ-RYY | 0.5*31C | 365 | 16.0 | 18 |
| WDZ-RYY | 0.5*32C | 374 | 16.0 | 18 |
| WDZ-RYY | 0.5*33C | 383 | 16.0 | 18 |
| WDZ-RYY | 0.75*2C | 47 | 6.2 | 6.6 |
| WDZ-RYY | 0.75*3C | 60 | 6.5 | 6.9 |
| WDZ-RYY | 0.75*4C | 74 | 7.1 | 7.5 |
| WDZ-RYY | 0.75*5C | 88 | 7.7 | 8.1 |
| WDZ-RYY | 0.75*6C | 102 | 8.4 | 8.8 |
| WDZ-RYY | 0.75*7C | 113 | 8.4 | 8.8 |
| WDZ-RYY | 0.75*8C | 137 | 9.5 | 9.9 |
| WDZ-RYY | 0.75*9C | 153 | 10.3 | 11.3 |
| WDZ-RYY | 0.75*10C | 167 | 11.0 | 12 |
| WDZ-RYY | 0.75*11C | 181 | 11.3 | 12.3 |
| WDZ-RYY | 0.75*12C | 203 | 11.7 | 12.7 |
| WDZ-RYY | 0.75*13C | 218 | 12.3 | 13.3 |
| WDZ-RYY | 0.75*14C | 229 | 12.3 | 13.3 |
| WDZ-RYY | 0.75*15C | 245 | 12.9 | 13.9 |
| WDZ-RYY | 0.75*16C | 256 | 12.9 | 13.9 |
| WDZ-RYY | 0.75*17C | 271 | 13.6 | 14.6 |
| WDZ-RYY | 0.75*18C | 283 | 13.6 | 14.6 |
| WDZ-RYY | 0.75*19C | 294 | 13.6 | 14.6 |
| WDZ-RYY | 0.75*20C | 308 | 13.9 | 14.9 |
| WDZ-RYY | 0.75*21C | 321 | 14.3 | 15.3 |
| WDZ-RYY | 0.75*22C | 338 | 15.1 | 17.1 |
| WDZ-RYY | 0.75*23C | 353 | 15.8 | 17.8 |
| WDZ-RYY | 0.75*24C | 365 | 15.8 | 17.8 |
| WDZ-RYY | 1.0*2C | 58 | 6.9 | 7.3 |
| WDZ-RYY | 1.0*3C | 75 | 7.3 | 7.7 |
| WDZ-RYY | 1.0*4C | 97 | 8.2 | 8.6 |
| WDZ-RYY | 1.0*5C | 116 | 8.9 | 9.3 |
| WDZ-RYY | 1.0*6C | 139 | 9.9 | 10.3 |
| WDZ-RYY | 1.0*7C | 159 | 10.1 | 11.1 |
| WDZ-RYY | 1.0*8C | 184 | 11.0 | 12 |
| WDZ-RYY | 1.0*9C | 206 | 12.0 | 13 |
| WDZ-RYY | 1.0*10C | 226 | 12.8 | 13.8 |
| WDZ-RYY | 1.0*11C | 244 | 13.2 | 14.2 |
| WDZ-RYY | 1.0*12C | 259 | 13.2 | 14.2 |
| WDZ-RYY | 1.0*13C | 278 | 13.9 | 14.9 |
| WDZ-RYY | 1.0*14C | 293 | 13.9 | 14.9 |
| WDZ-RYY | 1.0*15C | 313 | 14.6 | 15.6 |
| WDZ-RYY | 1.0*16C | 328 | 14.6 | 15.6 |
| WDZ-RYY | 1.0*17C | 348 | 15.4 | 17.4 |
| WDZ-RYY | 1.0*18C | 364 | 15.4 | 17.4 |
| WDZ-RYY | 1.0*19C | 379 | 15.4 | 17.4 |
| WDZ-RYY | 1.0*20C | 397 | 15.7 | 17.7 |
| WDZ-RYY | 1.25*2C | 75 | 7.9 | 8.3 |
| WDZ-RYY | 1.25*3C | 96 | 8.3 | 8.7 |
| WDZ-RYY | 1.25*4C | 119 | 9.1 | 9.5 |
| WDZ-RYY | 1.25*5C | 142 | 9.9 | 10.3 |
| WDZ-RYY | 1.25*6C | 166 | 10.8 | 11.2 |
| WDZ-RYY | 1.25*7C | 190 | 11 | 11.4 |
| WDZ-RYY | 1.25*8C | 219 | 12 | 12.4 |
| WDZ-RYY | 1.25*9C | 245 | 13.1 | 13.5 |
| WDZ-RYY | 1.25*10C | 270 | 14 | 14.4 |
| WDZ-RYY | 1.25*11C | 291 | 14.4 | 14.8 |
| WDZ-RYY | 1.25*12C | 310 | 14.4 | 14.8 |
| WDZ-RYY | 1.25*13C | 334 | 15.2 | 17.2 |
| WDZ-RYY | 1.25*14C | 353 | 15.2 | 17.2 |
| WDZ-RYY | 1.25*15C | 377 | 16.0 | 18 |
| WDZ-RYY | 1.25*16C | 395 | 16.0 | 18 |
| WDZ-RYY | 1.5*2C | 74 | 7.8 | 8.2 |
| WDZ-RYY | 1.5*3C | 102 | 8.5 | 8.9 |
| WDZ-RYY | 1.5*4C | 132 | 9.4 | 9.8 |
| WDZ-RYY | 1.5*5C | 163 | 10.5 | 11.5 |
| WDZ-RYY | 1.5*6C | 190 | 11.4 | 12.4 |
| WDZ-RYY | 1.5*7C | 211 | 11.4 | 12.4 |
| WDZ-RYY | 1.5*8C | 244 | 12.5 | 13.5 |
| WDZ-RYY | 1.5*9C | 273 | 13.7 | 14.7 |
| WDZ-RYY | 1.5*10C | 300 | 14.6 | 15.6 |
| WDZ-RYY | 1.5*11C | 325 | 15.1 | 17.1 |
| WDZ-RYY | 1.5*12C | 346 | 15.1 | 17.1 |
| WDZ-RYY | 1.5*13C | 373 | 15.8 | 17.8 |
| WDZ-RYY | 1.5*14C | 394 | 15.8 | 17.8 |
| WDZ-RYY | 2.0*2C | 99 | 9.0 | 9.4 |
| WDZ-RYY | 2.0*3C | 134 | 9.7 | 10.1 |
| WDZ-RYY | 2.0*4C | 168 | 10.6 | 11.6 |
| WDZ-RYY | 2.0*5C | 207 | 11.8 | 12.8 |
| WDZ-RYY | 2.0*6C | 241 | 12.8 | 13.8 |
| WDZ-RYY | 2.0*7C | 269 | 12.8 | 13.8 |
| WDZ-RYY | 2.0*8C | 303 | 13.8 | 14.8 |
| WDZ-RYY | 2.0*9C | 340 | 15.2 | 17.2 |
| WDZ-RYY | 2.0*10C | 374 | 16.2 | 18.2 |
| WDZ-RYY | 2.5*2C | 110 | 9.4 | 9.8 |
| WDZ-RYY | 2.5*3C | 150 | 10.2 | 11.2 |
| WDZ-RYY | 2.5*4C | 188 | 11.1 | 12.1 |
| WDZ-RYY | 2.5*5C | 232 | 12.3 | 13.3 |
| WDZ-RYY | 2.5*6C | 271 | 13.4 | 14.4 |
| WDZ-RYY | 2.5*7C | 303 | 13.4 | 14.4 |
| WDZ-RYY | 2.5*8C | 342 | 14.5 | 15.5 |
| WDZ-RYY | 4.0*2C | 152 | 10.7 | 11.7 |
| WDZ-RYY | 4.0*3C | 210 | 11.6 | 12.6 |
| WDZ-RYY | 4.0*4C | 279 | 12.8 | 13.8 |
| WDZ-RYY | 4.0*5C | 330 | 14.1 | 15.1 |
| WDZ-RYY | 4.0*6C | 388 | 15.4 | 17.4 |
| WDZ-RYY | 4.0*7C | 437 | 15.4 | 17.4 |
| WDZ-RYY | 6.0*2C | 207 | 12.2 | 13.2 |
| WDZ-RYY | 6.0*3C | 283 | 13.0 | 14 |
| WDZ-RYY | 6.0*4C | 368 | 14.4 | 15.4 |
| WDZ-RYY | 8.0*2C | 265 | 14.0 | 15.0 |
| WDZ-RYY | 8.0*3C | 365 | 14.9 | 15.9 |
